Client Authentication Enhancements

Centrifugo OSS provides JWT-based client authentication. It's a very powerful mechanism because it helps a lot to reduce load on your session backend when dealing with many concurrent connections and massive reconnections from time to time. Centrifugo PRO comes with extra features for more convenient client authentication management.

Extracting meta from JWT claims

Centrifugo PRO can automatically extract and populate connection meta object from JWT token claims based on the mapping in the configuration. This allows more convenient work with JWTs which are not under user's control, i.e., issued by third-party identity providers.

info

This feature is available since Centrifugo PRO v6.5.0, currently in beta status. Beta status means we can tweak some implementation details based on user feedback before marking it as stable.

This metadata is then available throughout the connection lifecycle and can be used in:

CEL expressions for authorization
Proxy requests (passed in per-call data)
Connection introspection

Example configuration

Meta claims extraction is configured using the meta_from_claim StringKeyValues option in the token configuration:

Keys are the field names to use in the resulting meta object (to be placed on meta object top level)
Values are paths to extract values from JWT claims (may have . for extracting nested objects from JWT claims)

Let's say we have the following configuration:

{
    "client": {
        "token": {
            "hmac_secret_key": "your-secret-key",
            "meta_from_claim": [
                {
                    "key": "role",
                    "value": "user.role"
                },
                {
                    "key": "dept",
                    "value": "user.department"
                },
                {
                    "key": "access_level",
                    "value": "permissions.level"
                },
                {
                    "key": "features",
                    "value": "enabled_features"
                },
                {
                    "key": "info",
                    "value": "custom-info"
                }
            ]
        }
    }
}

Given a connection JWT with the following claims:

{
    "sub": "user123",
    "exp": 1234567890,
    "user": {
        "role": "admin",
        "department": "engineering"
    },
    "permissions": {
        "level": 5
    },
    "enabled_features": ["dashboard", "api"],
    "custom-info": "some info"
}

With the example configuration above, Centrifugo will:

Extract user.role and map it to role in meta
Extract user.department and map it to dept in meta
Etc.

The connection will have the following meta object:

{
    "role": "admin",
    "dept": "engineering",
    "access_level": 5,
    "features": ["dashboard", "api"],
    "info": "some info"
}

Implementation notes

Meta field names (the keys in the meta_from_claim map) must follow ^[A-Za-z_][A-Za-z0-9_]*$ regex. This is validated on Centrifugo start.
Meta claims extraction allows using dots for extracting values from nested JWT claim objects. In meta_from_claim values, Centrifugo does not allow using special characters like @#[]{}*?! by default, but you can use the \ character to escape them if needed. Values are validated on Centrifugo start.
If a path in meta_from_claim value doesn't exist in the JWT token, it will be silently skipped. Only claims that exist in the token will be extracted.
If your JWT token already contains a meta claim, the extracted fields will override the existing fields.
Meta claims extraction only works for connection tokens, not subscription tokens. Subscription tokens do not support the meta claim.

Try it: claim mapping explorer

Edit the JWT claims, meta_from_claim, and labels_from_claim below and watch the resulting connection meta and labels — including which mappings were extracted, overrode an existing value, or were silently skipped. It also handles the labels_from_claim mapping described in the next section, and generates the config to reproduce it.

JWT claim mapping explorer

meta + labels

Connection JWT claims

meta_from_claim

←

labels_from_claim

←

Keys must match ^[A-Za-z_][A-Za-z0-9_]*$. Paths are simple dot paths; escape a literal dot as \.

Resulting connection state

Client labels

Client labels are a small string-to-string map (map[string]string) attached to a connection at connect time. Once set, labels are immutable for the connection's lifetime. Centrifugo PRO uses them as a first-class connection primitive across many subsystems — think of them as Kubernetes labels or Datadog tags for real-time connections: a categorical key/value space operators set once at auth time, then segment, filter, and target on for the connection's lifetime.

At a glance

Where labels are set	Where labels are used
JWT `labels` claim	Prometheus dimensions on per-client metrics
JWT `labels_from_claim` mapping (per token or per JWKS provider)	`label_filter` argument on server API `subscribe`/`unsubscribe`/`disconnect`/`refresh`
Connect proxy response `labels` field	Connections API filtering and listings
	`labels` variable in CEL expressions for channel-permission gates
	ClickHouse analytics `labels` column on `connections`, `operations`, `snapshot_connections`
	Snapshot `label_filter` at gather time
	Always attached on outgoing proxy requests (publish, subscribe, RPC, refresh, sub_refresh, map_publish, map_remove)

Labels vs `meta`

Centrifugo connections already have a meta JSON object that flows from JWT/proxy into per-connection metadata. Labels are a separate primitive with a narrower contract:

meta is free-form JSON. Use it when your backend needs richer per-connection context — nested objects, arrays, app-specific shapes. Not filterable on the server side.
labels is a typed map[string]string. Use it when the value is a categorical key/value pair you want to filter on, segment by, or target with an op (metrics dimensions, server-API label_filter, listings, CEL gates, analytics columns).

Rule of thumb: tier/region/app-version → labels. Anything richer than a string-keyed string value → meta. The same JWT claim can populate both — use whichever shape fits the consumer. Both are immutable after connect.

Sources

Centrifugo PRO accepts client labels from two sources:

A top-level labels claim in the connection JWT.
The labels_from_claim mapping (see Extracting labels from JWT claims below), analogous to meta_from_claim.

When both are present, mapped entries from labels_from_claim override entries from the top-level labels claim on key collisions.

Top-level `labels` claim

The simplest path — put a labels object on your JWT:

{
    "sub": "user42",
    "exp": 1799999999,
    "labels": {
        "region": "eu",
        "tier": "pro",
        "app_version": "3.4.1"
    }
}

All string keys and string values are accepted.

Extracting labels from JWT claims

When the labels you want live on existing JWT claims (often the case with third-party identity providers), use labels_from_claim — same shape and semantics as meta_from_claim. Keys become label keys in the resulting map; values are gjson paths into the JWT claims.

{
    "client": {
        "token": {
            "hmac_secret_key": "your-secret-key",
            "labels_from_claim": [
                { "key": "region", "value": "deployment.region" },
                { "key": "tier", "value": "subscription.tier" }
            ]
        }
    }
}

Given a JWT with claims {"deployment": {"region": "eu"}, "subscription": {"tier": "pro"}, "sub": "user42"}, the connection labels become {"region": "eu", "tier": "pro"}.

Implementation notes

labels_from_claim is configured per-token (client.token.labels_from_claim) and optionally per-JWKS-provider (client.token.jwks.providers[].labels_from_claim). Per-provider config wins over global config when a provider matches a token's issuer.
Missing JWT paths are silently skipped — no empty-string insertion.
Non-string scalar values from JWT claims are stringified with gjson Result.String() semantics: numbers keep their plain decimal form (no scientific notation, even for large integers), booleans become "true" / "false", and arrays/objects become their raw JSON text.
labels_from_claim only works for connection tokens. Subscription tokens do not carry connection labels (validated on Centrifugo start).
Labels are immutable post-connect. To change a label value, the client must reconnect with a new token.
Avoid putting high-cardinality values (user IDs, session IDs) into labels — they end up as Prometheus dimensions (when prometheus.client_labels is set) and as a ClickHouse Map(String, String) column (when analytics is enabled). See the corresponding sections for the cardinality discussion.

From the connect proxy response

When authentication is delegated to your backend via the connect proxy, the proxy response may include a top-level labels field with the same shape (map<string, string>). Centrifugo PRO attaches those labels to the connection just like the JWT path. When both a JWT and a connect proxy run for the same connection, the connect proxy wins (same precedence as meta).

{
  "result": {
    "user": "user42",
    "labels": {"region": "eu", "tier": "pro"}
  }
}

Outgoing proxy requests always carry labels

For every outgoing proxy request that already carries meta (publish, subscribe, RPC, refresh, sub_refresh, map publish, map remove), Centrifugo PRO always attaches the connection's labels as a top-level labels map. Unlike meta, this has no configuration toggle — labels are PRO-only and small, so opt-in adds friction without protecting against bloat (keep label cardinality low at the source instead).

{
  "client": "abc123",
  "user": "user42",
  "channel": "chat:room",
  "data": {"text": "hi"},
  "labels": {"region": "eu", "tier": "pro"}
}

Backends can use the labels for routing, authorization, or correlation without a separate lookup against your session store.

Consumers

Labels are one primitive flowing through many subsystems. This page is the reference for setting them; each consumer documents its own contract:

Server API enhancements — label_filter and all_users on subscribe/unsubscribe/disconnect/refresh (including fleet-wide targeting).
Connections API — label_filter on listings; the snapshot create endpoint accepts a gather-time label_filter.
CEL expressions — the labels variable in channel-permission expressions.
Observability enhancements — the prometheus.client_labels option, the app_* Prometheus dimension prefix, and the cardinality warning.
ClickHouse analytics — the labels column on connections, operations, and snapshot_connections, plus the one-time ALTER TABLE migration for existing deployments.
Event hooks — the connect proxy labels response field and the always-attached labels on outgoing proxy requests.

Keep cardinality bounded

Labels become Prometheus dimensions (when prometheus.client_labels is set) and ClickHouse Map(String, String) columns (when analytics is enabled). Never put user IDs, session IDs, request IDs, or other unbounded values into labels — they explode metric series and degrade analytics compression. Use bounded categorical sets: region (5–20 values), tier (3–5 values), app_version (dozens). The same rule applies to label keys — they are the column dictionary in ClickHouse.

Multiple JWKS Providers

Centrifugo PRO supports configuring multiple JWKS (JSON Web Key Set) providers for client connection authentication with automatic token routing based on the issuer (iss) claim. This may be useful for multi-tenant scenarios where tokens may come from different identity providers.

info

This feature is available since Centrifugo PRO v6.5.0, currently in beta status. Beta status means we can tweak some implementation details based on user feedback before marking it as stable.

While the standard client.token.jwks_public_endpoint configuration allows fetching public keys from a single JWKS endpoint, this feature enables you to configure multiple JWKS endpoints, each associated with a specific token issuer. Centrifugo will automatically route token verification to the correct provider based on the iss (issuer) claim in the JWT.

Note: client.token.jwks_public_endpoint and client.token.jwks.providers are mutually exclusive at this point — you cannot use both at the same time.

Configuration

{
    "client": {
        "token": {
            "jwks": {
                "enabled": true,
                "providers": [
                    {
                        "name": "auth0",
                        "enabled": true,
                        "endpoint": "https://tenant.auth0.com/.well-known/jwks.json",
                        "issuer": "https://tenant.auth0.com/",
                        "audience": "centrifugo"
                    },
                    {
                        "name": "keycloak",
                        "enabled": true,
                        "endpoint": "https://keycloak.example.com/realms/myrealm/protocol/openid-connect/certs",
                        "issuer": "https://keycloak.example.com/realms/myrealm",
                        "audience": "centrifugo"
                    }
                ]
            }
        }
    }
}

note

The client.token.jwks.enabled field must be set to true to enable multiple JWKS providers feature. Without it, the providers configuration will be ignored.

Same issuer with different audiences

Starting from Centrifugo PRO v6.5.2, you can configure multiple providers with the same issuer but different audiences. This is useful when:

A single identity provider issues tokens for multiple applications (web, mobile, API) with different audience claims
You want to apply different configurations (e.g., different meta_from_claim mappings) for tokens from the same issuer but intended for different audiences
You need to segregate or route tokens based on both issuer and audience

{
    "client": {
        "token": {
            "jwks": {
                "enabled": true,
                "providers": [
                    {
                        "name": "auth0_web",
                        "enabled": true,
                        "endpoint": "https://tenant.auth0.com/.well-known/jwks.json",
                        "issuer": "https://tenant.auth0.com/",
                        "audience": "web-app"
                    },
                    {
                        "name": "auth0_mobile",
                        "enabled": true,
                        "endpoint": "https://tenant.auth0.com/.well-known/jwks.json",
                        "issuer": "https://tenant.auth0.com/",
                        "audience": "mobile-app"
                    },
                    {
                        "name": "auth0_api",
                        "enabled": true,
                        "endpoint": "https://tenant.auth0.com/.well-known/jwks.json",
                        "issuer": "https://tenant.auth0.com/",
                        "audience": "api-service"
                    }
                ]
            }
        }
    }
}

In this configuration:

Tokens with iss=https://tenant.auth0.com/ and aud=web-app will be matched to the auth0_web provider
Tokens with iss=https://tenant.auth0.com/ and aud=mobile-app will be matched to the auth0_mobile provider
Tokens with iss=https://tenant.auth0.com/ and aud=api-service will be matched to the auth0_api provider
Tokens with the same issuer but an unrecognized audience will be rejected

Validation rules:

If the same issuer appears in multiple enabled providers, each provider MUST have a different audience set.
Duplicate issuer+audience pairs are not allowed.
Providers with the same issuer cannot have empty audiences.

JWKS configuration

Field	Type	Required	Description
enabled	`boolean`	yes	Must be `true` to enable multiple JWKS providers functionality
providers	`array`	yes	Array of JWKS provider configurations (see below)

JWKS provider fields

Field	Type	Required	Description
name	`string`	yes	Unique identifier for the provider. Must match pattern `^[a-zA-Z0-9_]{2,}$`
enabled	`boolean`	no	Whether this provider is active (default `false`)
endpoint	`string`	Yes*	JWKS endpoint URL (*required if enabled)
issuer	`string`	Yes*	Expected issuer claim value (*required if enabled)
audience	`string`	no	Expected audience claim value. While optional, it's highly recommended to set this in most cases to prevent client tokens related to other audiences issued by the same issuer from being accepted by Centrifugo. When the same issuer is used by multiple providers, each must have a different audience set to enable issuer+audience matching
tls	`TLS` object	no	Custom TLS configuration for the JWKS endpoint HTTP client
meta_from_claim	StringKeyValues	no	Config to transform JWT claims to connection meta object. Must be explicitly set for each provider, not inherited from upper config level.
labels_from_claim	StringKeyValues	no	Config to transform JWT claims to connection labels. Must be explicitly set for each provider, not inherited from upper config level.

How It Works

Token Received: When a client connects with a JWT token, Centrifugo parses it
Issuer Extraction: The iss claim is extracted from the token
Provider Matching: Centrifugo finds the JWKS provider based on issuer and audience:
- If a provider has an audience configured, both issuer AND audience must match (exact match prioritized)
- If a provider has no audience configured, only the issuer needs to match (fallback match)
- This enables routing tokens from the same issuer to different providers based on audience
Key Retrieval: Public keys are fetched from the matched provider's endpoint
Signature Verification: The token signature is verified using the retrieved keys

If no provider matches the token's issuer (and audience when applicable), the connection is rejected.

Try it: provider routing explorer

Paste a token's claims, edit the providers, and see which one it routes to — or why it's rejected — then the meta and labels produced by that provider's own meta_from_claim / labels_from_claim (expand a provider's claim mappings to edit them). The explorer also flags configurations that would be rejected at startup (duplicate issuer+audience, a repeated issuer without distinct audiences, invalid names).

JWKS provider routing explorer

→ auth0_web

Incoming token claims

iss https://tenant.auth0.com/aud web-app

Configured providers

Routing decision

✓auth0_web — issuer matches and audience "web-app" is in the token aud

Verified with auth0_web, using its claim mappings:

Subscription token

JWKS providers work for both connection tokens and subscription tokens. As usual, configuration must be separate:

{
    "client": {
        "token": {
            "jwks": {
                "enabled": true,
                "providers": [{
                    "name": "auth0_connection",
                    "enabled": true,
                    "endpoint": "https://tenant.auth0.com/.well-known/jwks.json",
                    "issuer": "https://tenant.auth0.com/",
                    "audience": "centrifugo"
                }]
            }
        },
        "subscription_token": {
            "enabled": true,
            "jwks": {
                "enabled": true,
                "providers": [{
                    "name": "subscription_identity",
                    "enabled": true,
                    "endpoint": "https://tenant.example.com/.well-known/jwks.json",
                    "issuer": "https://tenant.example.com",
                    "audience": "centrifugo"
                }]
            }
        }
    }
}

Notes:

meta_from_claim is not supported for subscription tokens, as subscription tokens do not support the meta claim at this moment. This is validated on Centrifugo start.
labels_from_claim is also not supported for subscription tokens — connection labels are a connect-time primitive only.
Issuer+audience matching works the same way for subscription tokens as it does for connection tokens — you can configure multiple providers with the same issuer but different audiences.

Extracting meta from JWT claims​

Example configuration​

Implementation notes​

Try it: claim mapping explorer​

JWT claim mapping explorer

Client labels​

At a glance​

Labels vs meta​

Sources​

Top-level labels claim​

Extracting labels from JWT claims​

Implementation notes​

From the connect proxy response​

Outgoing proxy requests always carry labels​

Consumers​

Multiple JWKS Providers​

Configuration​

Same issuer with different audiences​

JWKS configuration​

JWKS provider fields​

How It Works​

Try it: provider routing explorer​

JWKS provider routing explorer

Subscription token​

Extracting meta from JWT claims

Example configuration

Implementation notes

Try it: claim mapping explorer

Client labels

At a glance

Labels vs `meta`

Sources

Top-level `labels` claim

Extracting labels from JWT claims

Implementation notes

From the connect proxy response

Outgoing proxy requests always carry labels

Consumers

Multiple JWKS Providers

Configuration

Same issuer with different audiences

JWKS configuration

JWKS provider fields

How It Works

Try it: provider routing explorer

Subscription token
